Huawei PILA 1 way -48V DC DC power supply board H901PILA

Huawei PILA 1 way -48V DC DC power supply board H901PILA

Product Description

Huawei MA5800 X7/X15/X17 DC connect power board

The H901PILA board leads in 1 -48 V or -60 V DC power through 2 100 A OT terminals, and transfers the power to the protection circuit, then to the filter circuit, and finally to the backplane, supplying power to the service subrack and other boards.

Functional Specifications

The H901PILA board supports the following features and specifications:

1 -48 V or -60 V DC power input (input voltage range: -38.4 V to -72 V)

Filtering and current-limiting for the power input port

Detection of power input and protection fuse faults

Protection alarm and board detection

H901PILA Board Description

The H901PILA board leads in one -48 V DC power through two 100 A OT terminals, and transfers the power to the protection circuit, then to the filter circuit, and finally to the backplane, supplying power to the service subrack and other boards.

Features and Specifications

The H901PILA board supports the following features and specifications:

One -48 V DC power input

Filtering and current-limiting for the power input port

Power input detection and protection fuse fault detection

Reporting of the protection alarm and board online signal

Parameters

Board Parameter

You can query power consumption, weight, maximum frame size, and normal operating temperature of all boards.

Table 1 lists the power consumption, weight, and maximum frame size of boards.

The operating temperature of H901XSED and H901TWED is -40°C to +55°C (in MA5800–X17/X15/X7) or -40°C to +65°C (in MA5800–X2) and the lowest board startup temperature is -25°C. The operating temperature of other boards is -40°C to +65°C and the lowest board startup temperature is -25°C.

NOTE:

The power consumption of a board is calculated based on the following conditions:

Operating voltage: -53.5 V DC.

Ambient temperature: 25°C.

Static power consumption: All ports do not carry any loads and optical modules are not installed on optical ports.

Maximum power consumption: All ports fully carry loads.

The board power consumption slightly varies with the power module configured for the board and discreteness of components.

Table 1 Power consumption and maximum frame size of boards

Our Advantages

We have Huawei H901PILA for sale, including refurbished and new ones, and the price is usually 90% lower than the original supplier's price. Our super fast turnaround time and high-quality inventory all over the world mean that we can accurately deliver the products replaced on the same day to the place where they are needed, and minimize network downtime.

Huawei H901PILA, like all our hardware, takes comprehensive warranty as the standard. Whether you need new products or renovated products, we only purchase green market equipment of the highest quality and environmental protection. All these are provided at the best possible price, and a large amount of cost-effectiveness will be directly passed on to you.

Huawei H901PILA represents only one product in our world-class hardware portfolio. The portfolio includes very well-known industry names, such as Nokia, Huawei, ZTE, Siemens, Nortel, Ericsson, Alcatel, Lucent, etc. We have a lot of inventory, thank you very much for sharing with customers.
